MoFi Electronics Studio Tracker
$199.00
MoFi cartridges are designed by looking back at where a record starts: On a lacquer cutting lathe like the model used at Mobile Fidelity Sound Lab. StudioTracker features a V-Twin dual-magnet generator that mirrors the layout of the cutting head that originally made a record’s grooves.
V-TWIN DUAL-MAGNET GENERATOR
Employing two low-mass, powerful magnets aligned in a V formation parallel with the stereo record grooves, StudioTracker accurately extracts precious details from your LPs.
ELLIPTICAL DIAMOND STYLUS
With a polymer body and elliptical stylus, StudioTracker offers surprising bang-for-your-buck value and a rich sound distinguished with a smooth, slightly forgiving top end.
FEATURES
• V-Twin dual-magnet generator
• Elliptical stylus
• Polymer body
• 3.5mV output
SPECIFICATIONS
Type Dual Magnet (MM) Stereo
Stylus Elliptical
Output Voltage 3.5mV
Frequency Response 20–20,000Hz
Weight 6.4g
Tracking Force 1.8–2.2g
Impedance 47kOhm
Capacitance 100pF
Compliance Static compliance : 35 x 10e-6/dyne
Dynamic compliance : 8 x 10e-6/dyne
